- Description
- Specification
- Optional
| Cross Slideways | Cross Movement | Vertical Downfeed | Auto Down Feed | Rotary Table |
|---|---|---|---|---|
| Double Vee Ways | Servo Control | Servo Control | S2 Standard | Bearings/Hydrostatic |
- The surfaces of longitudinal table ways are all hand scraped to getting perfect contact pattern and to ensure very high accuracy.
- ongitudinal table ways are designed to have slide surfaces longer than that of the working surface and equal to the table length to keep the table free from torsion and deflection.
| SPECIFICATION / MODELS |
PSRC | ||
|---|---|---|---|
| 600VS | |||
| General Capacity | Max. grinding radius | mm | 340 |
| Spindle center height from table | mm | 300 | |
| Rotary Table | Table diameter | mm | 600 |
| Max. speed | r.p.m. | 100 | |
| Vertical Downfeed | Rapid traverse-approx. | mm/min | 500 |
| MPG feed per revolution | 0.1mm x1/x5/x10 | ||
| MPG feed per divison | 0.001mm x1/x5/x10 | ||
| Grinding Wheel | Dimension (O.D) | mm | φ500 |
| Spindle speed(50/60Hz) | r.p.m. | 1800 | |
| Motor | Spindle motor | 11kW/15HP | |
| Table motor | 3kW | ||
| Weight | Net weight | kg | 5000 |
| Gross weight | kg | 6000 | |
| Machine Size | Dimension(L x W x H) | m | 2.62x2.37x2.33 |
Notes:
- Since we subscribe to a process of continuous improvement for our products specifications are subject to change without notice.
- Machine appearance will change depending upon different optional equipment selected.
- Equipment marked with () is available at additional extra charge. Other special applications may be provided upon specific requests from customers. Please contact us for more details.
- Machines are shown with optional equipments.
Wheel Flange
Radius and Angle Dresser
(PSGS)
Parallel Dressing Attachment (Manual Type for PSGS) ※With The Exception of PSGS-1535M, 1545M, 2045M
Cross/Vertical Micrometer Attachment (PSGS-2550AH, 3060BH, 4080AHR)
Cooling System
Level Type Wheel Balancer
Electro Magnetic Chuck
Automatic Paper Serip Filter
Cooling System Magnetic Separator
Parallel Dressing Attachment (PSGO)
Dust-Suction Cooling System(PSGS)
Auto-Parallel Dressing Attachment 2 Axes Full Auto (Electrical Cross+Step Control Down)
1.Window Type Splash Guard (PSGS) 2.Rear Side Coolant Baffle (PSGS)
Oil Temperature Control System
Oil Mist Collector
